-40℃ Freezer

This -40℃ freezer offer energy and space savings and are ideal for storage applications.

Model : LFZ-P40V270E; LFZ-P40V280E; LFZ-P40V270E; LFZ-P40V360; LFZ-P40V370; LFZ-P40V530; LFZ-P40V1000;
Sensor : NTC
Controller : Microprocessor
Defrost : Manual
Temperature Range (℃) : -20~-40

Description

The -40℃ freezer is one of the key indispensable pieces of equipment for the modern laboratory, providing a safe and reliable environment for storing your samples. Whether it’s biological samples, chemical reagents or pharmaceutical samples, this ultra-low temperature refrigerator ensures their long-term preservation and stability at extremely low temperatures.

-40℃ Freezer Specifications:

Model		LFZ-P40V270E	LFZ-P40V280E	LFZ-P40V270E	LFZ-P40V360	LFZ-P40V370	LFZ-P40V530	LFZ-P40V1000
Capacity (L)		268	278	328	358	368	528	936
Size (WxDxH)(mm)	Internal	508x455x1137	480x415x1460	508x455x1393	466x636x625	F:580x626x625 R:466x636x625	(651×631.5×635)x2	1000x700x1335
Size (WxDxH)(mm)	External	673x676x1630	659x600x1694	673x676x1886	720x830x1870	720x830x1870	900x818x1875	1304x1000x2017
Temperature Range (℃) at RT. 10~32℃		-20~-40	-20~-40	-20~-40	-20~-40	F: -20～-40 R: 2～8	-20~-40	-25~-40
Sensor		NTC	NTC	NTC	NTC	NTC	NTC	PTC
Controller		Microprocessor
Cooling Stystem	Refrigerant	R290 (CFC Free)
	Defrost	Manual
	Compressor (Qty)	CUBIGEL/1	CUBIGEL/1	CUBIGEL/1	CUBIGEL/2	CUBIGEL/1 HUAYI/1	CUBIGEL/1	SECOP/2
Display		Digital display
Audible & Visible Alarm	Standard	High/Low temperature, Sensor error
	High Ambient Temperature	/	/	/	Standard	Standard	Standard	Standard
	Low Battery	/	/	/	/	/	/	Standard
	Power Failure Backup System (alarm)	8h	/	8h	8h	8h	8h	72h
Material	Internal	Electro-galvanized steel with antimicrobial powder coating						Stainless steel grade 304
Material	External	Electro-galvanized steel with antimicrobial powder coating
Accessories	USB Port	/	/	/	Standard	Standard	Standard	Standard
	Casters	Standard	Standard	Standard	Standard	Standard	Standard	/
	Remote Alarm Port	Standard	/	Standard	Optional	Optional	Standard	Standard
	Test Hole (Qty / Diameter (mm)	2/20
Shelves / Drawers (Qty)		Shelves/3	Drawers/7	Shelves/4	Shelves/4 Drawers/12	Shelves/2 Drawers/6	Shelves/4 Drawers/18	Shelves/3
Sound Emission (dB)		48	50	48	49	50	55	50
Electricity	Voltage/Frequency	AC110/220V±10%, 50/60Hz
Electricity	Consumption (W)	300	280	300	310	430	340	1000
N.W./G.W. (Kg)		98.5/118	79/104.5	110.3/132	138/178	137/166	151/184	372/416
Shipping Size (WxDxH) (mm)		760x760x1750	725x665x1850	750x760x2030	780x920x1990	775x920x1990	930x970x2000	1360x1135x2170

-40℃ Freezer Feature:

Convenient operation: clear LED screen and control panel for easy and convenient operation.
Flexible movement: with lockable universal swivel wheels for easy movement and fixing.
Intelligent design: Interior design with inner door or drawer for segregated storage.
Eco-friendly and energy-saving: CFC-free refrigerant is used to save energy and protect the environment.
Reliability: Audible buzzer and visible flashing temperature alarm system to guarantee temperature stability. Secure password-protected control panel prevents unauthorised system modifications. Door lock safeguards storage security.
Ergonomic design: Upright door design with limiting door hinges to prevent collision when the door is opened. Controller password protection to prevent unauthorised system modifications. Plus lockable universal swivel wheels to move equipment easily.
