Horizontal Pressure Steam Autoclave

Model : LST-PH150I; LST-PH200I; LST-PH300I; LST-PH400I
Capacity (L) : 150 / 200 / 300 / 400
Chamber Size (ØxH)(mm) : Ø472×880 / Ø472×1150 / Ø620×995 / Ø620×1320
Working Temperature (℃) : 105-136
Sizes (WxDxH)(mm) : 1290x690x1680; 1560x690x1680; 1430x850x1760; 1755x850x1760

Category: Horizontal Autoclave

Description

Description

Horizontal Pressure Steam Autoclave Feature:

Circular chamber with jacket design for safety, heat preservation, and drying.
HMI touch screen and microcomputer control for intuitive operation.
Disc-type gear and electric lock door for secure and reliable use.
Self-expanding door seals ensure effective sealing.
Standard calibration interface for easy equipment validation.
SUS 304 pipeline with clamp system allows quick assembly.
FO value and temperature-time ensure sterilization with detailed records.
Safety features include over-temperature and over-pressure protection.
Built-in printer and USB for data logging.

Horizontal Pressure Steam Autoclave Specifications:

Model	LST-PH150I	LST-PH200I	LST-PH300I	LST-PH400I
Volume (L)	150	200	300	400
Steam Consumption (KG)	≤12	≤13	≤18	≤22
Water Consumption (KG)	≤30	≤30	≤40	≤40
Power (KW)	≤2+⑮	≤2+⑮	≤2+⑱	≤2+⑱
Chamber Size (ØxL)(mm)	Ø472×880	Ø472×1150	Ø620×995	Ø620×1320
Sizes (WxDxH)(mm)	1290x690x1680	1560x690x1680	1430x850x1760	1755x850x1760
Shipping Size (WxDxH)(mm)	1570x840x1850	1740x840x1850	1610x990x1900	1935x990x1900
N.W./G.W. (kg)	400/500	450/550	510/610	650/750
Design Pressure	-0.1~0.25Mpa
Design Temperature	139℃
Working Pressure	0.225Mpa
Working Temperature	105-136℃
Temp Accuracy	±1℃
Temperature Equilibrium	<+2.0℃
Water Pressure	0.1-0.2Mpa
Compressed Air Pressure	0.4~0.7Mpa
Steam Pressure	0.3-0.7Mpa
Power Voltage	Three-phase five-wire AC 380V 50Hz
